AP6212 is a total solution for a combination of WiFi + BT + FM technologies. The module complies with IEEE 802.11 b/g/n standard and it could achieve up to a speed of 72.2Mbps with single stream in 802.11n draft, 54Mbps as specified in 802.11g, or 11Mbps for 802.11b to connect to the wireless LAN. The integrated module provides SDIO interface for WiFi, UART / PCM for Bluetooth and UART / I2S / PCM interface for FM.
AP6212's Features
1.802.11b/g/n single-band radio
2.Bluetooth V4.0(HS) with integrated Class 1.5 PA and Low Energy (BLE) support
3.Concurrent Bluetooth, FM (RX) RDS/RBDS, and WLAN operation
4.Simultaneous BT/WLAN receive with single antenna
5.WLAN host interface options:
-SDIO v2.0 — up to 50 MHz clock rate
6.BT host digital interface:
-UART (up to 4 Mbps)
7.FM multiple audio routing options: I2S, PCM, eSCO, A2DP
8.IEEE Co-existence technologies are integrated die solution
9.ECI — enhanced coexistence support, ability to coordinate BT SCO transmissions around WLAN receives
AP6212's Block Diagram
AP6212's Appliacation
1.Tablet
2.Smart phones
3.Portable devices
AP6212's Package
