GD32F103ZCT6

ARM® CortexTM-M3 core

• Frequency up to108 MHz

• Single-cycle multiplier and hardware divider

• NVIC support 16 interrupts, each interrupt has 16 priority levels

• Flash memory

Flash up to 3072 KB

• SRAM up to 96 KB

• 2KB ISP loader ROM

Low-power management

• Support power saving mode: sleep, deep-sleep and standby mode

• Independent battery supply for RTC and backup register

High performance analog peripherals

• 3 x 12bit, 1μs ADC

• 2 x DAC

Varity of peripherals interface

• Up to 5 x USART/Irda/LIN/ISO7816

• Up to 3 x SPI (18Mbit/s)

• Up to 2 x I2C (400Kbit/s)

• Up to 2 x CAN 2.0 B (1Mbit/s)

• USB 2.0 FS (12Mbit/s)

On-chip resources

• 1 x Advanced Timer, 1 x SysTick Timer, up to 10 x GPTM, 2 x WDT

• 2 x DMA supported

• POR,PDR and LVD

• 80% available GPIO

• 32 bit CRC

• Clock: HSI (8MHz) and LSI (40KHz)

• External Memory Control supported: SRAM, PSRAM, NOR-Flash, LCD
